APPROACH LIGHTS

Utilizing over 60 years of experience, Millard frangible approach light masts are designed for safety, durability and serviceability.  Standard designs range from 1.2m to 14m although extra tall solutions up to 60m are available.

SAFE.  ICAO COMPLIANT

  • The world’s first frangible mast developed over 60 years ago
  • ICAO frangibility compliant through 3rd party full-scale impact testing
  • Meets ICAO deflection criteria of 2 degrees in the vertical axis and 5 degrees in the horizontal axis
  • The unique Aluminum lattice structure is rigid, yet engineered to give way if accidentally impacted

DURABLE.  STRONG.

  • Typical lifespan of 25+ years
  • Aluminum alloy used to build Millard masts is the same used to build spacecraft and marine vessles
  • Naturally resistant to Saltwater and UV exposure without the use of gels or coatings
  • Virtually maintenance free and no special handling or treatments required
  • Backed by an industry best 10 year warranty

SERVICEABLE.  EASY TO USE.

  • Lightweight for easy on-site handling
  • Tilt base and center hinge features allow mast to be installed and serviced quickly and safely
  • Simple and modular design comes together easily to minimize contractor labour
  • Lamp height easily adjustable

– Please leave this line unchanged or subscribe for a premium HTML editor membership at htmlg.com

Thursday, 16 March 2017 00:00

METEOROLOGY

Millard meteorological masts are ideal for their simplicity and reliable performance.  The masts are ICAO frangibility compliant through 3rd party full-scale impact testing.  Standard designs are for heights 2.25m, 3m, 6m and 10m, but other solutions are available.

SIMPLE. UNIVERSAL. EASY.

  • Simple design can be installed by anyone using basic hand tools
  • Lightweight for easy on-site handling
  • Tilt base and center hinge features allow mast to be installed and serviced quickly and safely
  • Lattice structure does not require special or custom hardware kits to mount equipment – standard u-bolts can be used.

RELIABLE. STRONG. DURABLE.

  • Engineered to stringent CSA (Canadian) wind and ice load standards to ensure reliable performance of mounted equipment.  Custom load engineering is available.
  • Rugged Aluminum alloy design is resistant to UV exposure and ideal for coastal regions
  • Typical lifespan of 25+ years and backed by an industry best 10 year warranty

Common applications include:

  • AWOS
  • Anemometers
  • RVR Systems
  • Various Sensors – air temperature, precipitation, humidity, etc.
  • Custom solutions available
Thursday, 16 March 2017 00:00

WINDSOCKS

Millard offers a complete line of frangible windsock masts that are safe, easy to use and durable.  The mast and its mechanical features offer a typical life expectancy of 20+ years.  Typical heights are 3m and 6m although other heights are available.

  • ICAO compliant as verified through 3rd party full-scale impact testing
  • Built for 170km/h wind and 12.5mm ice loading and not subject to fatigue or deformation as with pole-style masts
  • Resistant to extreme UV and saltwater exposure
  • Tilt base option allows for mast and windsock to be installed on the ground and raised into position by hand
  • Center hinge option allows the wind cone to be serviced from the ground by a single technician using a worm gear winch

Millard also offers all wind cone components in compliance with ICAO requirements:

  • Fabric windsocks
  • Basket and Swivel assemblies
  • 110V to 240V and 6.6A Circuit Series Electrical Configurations
  • Internally/Externally Lit LED Assembly
  • Solar Powered kits
  • LED Obstruction Lighting
Thursday, 16 March 2017 00:00

FRANGIBLE ILS

Millard’s complete line of ILS masts provides reliable performance for critical airfield equipment ensuring that specified deflection criteria is met.  Millard also supplies installation kits to allow equipment to be installed and adjusted with ease.  As with all of Millard Frangible Aviation masts, ILS masts are ICAO compliant, have a typical lifespan of 25+ years and are backed by an industry best 10-year warranty.

Applications include:

  • ILS Glide Path
  • ILS Localizers
  • Near Field Monitors
  • Far-Field Monitors
  • DME Antennas

Custom mounts can be fabricated in-house by Millard ensuring full system integration.

As ILS equipment is sensitive and critical for the safe operation of an airfield, Millard treats each ILS project as unique and provides custom engineering on a project-by-project basis.  Equipment deflection and specific site wind and ice loads must be considered.

Thursday, 16 March 2017 00:00

COMMUNICATION

Millard engineers and manufactures guyed masts to support antennas of all varieties, including HF, VHF and UHF arrangements.  Masts are made from marine-grade Aluminum alloy and favoured for their simple design, easy installation and rugged durability.  Standard heights available up to 60m.

  • Engineered per CSA S37-13 – Antennas, Towers and Antenna-Supporting Structures
  • Fabricated in 3m lengths, weighing between 8kg and 35kg
  • Masts are light enough to be transported to site by hand or helicopter
  • Optional gin pole, boom or hinge base assemblies allow masts to be erected without a crane and with as few as two workers
  • Optional ladder, fall arrest kits, climb guards, lightning kits, obstruction lighting and mounting brackets are available
  • Masts are available as unpainted, solid powder coated or banded powder coating per obstruction marking requirements

Common Applications include:

  • HF, UHF, and VHF
  • Directional
  • Omni-Directional
  • Dipole
  • Rhombic
  • Cross-Loop
  • YAGI
  • Delta
  • Whip
Thursday, 16 March 2017 00:00

MARINE NAVIGATION

Used by marine agencies worldwide, Millard masts are used to support navigational aids for coastlines and shipping channels.  Masts are ideal for remote locations where installation and maintenance is difficult and costly.  Various designs are available depending upon application and location.

  • Engineered per CSA S37-13 – Antennas, Towers and Antenna-Supporting Structures
  • Fabricated in 3m lengths, weighing between 12kg and 35kg, from marine-grade Aluminum alloy
  • Masts are light enough to be transported to site by hand or assembled off-site and lifted by helicopter
  • Design allows for easy installation on difficult and irregular surfaces such as rock and tundra
  • Optional ladder, fall arrest kits, climb guards, lightning kits, obstruction lighting and mounting brackets are available
  • Masts are available as unpainted, solid powder coated or banded powder coating per obstruction marking requirements

Common Applications include:

  • Daymarks
  • Beacons
  • Radar Deflectors
  • Lamps
  • Foghorns
  • Communications Equipment
  • Solar Panels
Thursday, 16 March 2017 00:00

MARINE NAVIGATION

Used by marine agencies worldwide, Millard masts are used to support navigational aids for coastlines and shipping channels.  Masts are ideal for remote locations where installation and maintenance is difficult and costly.  Various designs are available depending upon application and location.

  • Engineered per CSA S37-13 – Antennas, Towers and Antenna-Supporting Structures
  • Fabricated in 3m lengths, weighing between 12kg and 35kg, from marine-grade Aluminum alloy
  • Masts are light enough to be transported to site by hand or assembled off-site and lifted by helicopter
  • Design allows for easy installation on difficult and irregular surfaces such as rock and tundra
  • Optional ladder, fall arrest kits, climb guards, lightning kits, obstruction lighting and mounting brackets are available
  • Masts are available as unpainted, solid powder coated or banded powder coating per obstruction marking requirements

Common Applications include:

  • Daymarks
  • Beacons
  • Radar Deflectors
  • Lamps
  • Foghorns
  • Communications Equipment
  • Solar Panels
Thursday, 16 March 2017 00:00

COMMUNICATION

Millard engineers and manufactures guyed masts to support antennas of all varieties, including HF, VHF and UHF arrangements.  Masts are made from marine-grade Aluminum alloy and favoured for their simple design, easy installation and rugged durability.  Standard heights available up to 60m.

  • Engineered per CSA S37-13 – Antennas, Towers and Antenna-Supporting Structures
  • Fabricated in 3m lengths, weighing between 8kg and 35kg
  • Masts are light enough to be transported to site by hand or helicopter
  • Optional gin pole, boom or hinge base assemblies allow masts to be erected without a crane and with as few as two workers
  • Optional ladder, fall arrest kits, climb guards, lightning kits, obstruction lighting and mounting brackets are available
  • Masts are available as unpainted, solid powder coated or banded powder coating per obstruction marking requirements

Common Applications include:

  • HF, UHF, and VHF
  • Directional
  • Omni-Directional
  • Dipole
  • Rhombic
  • Cross-Loop
  • YAGI
  • Delta
  • Whip
Thursday, 16 March 2017 00:00

FRANGIBLE ILS

Millard’s complete line of ILS masts provides reliable performance for critical airfield equipment ensuring that specified deflection criteria is met.  Millard also supplies installation kits to allow equipment to be installed and adjusted with ease.  As with all of Millard Frangible Aviation masts, ILS masts are ICAO compliant, have a typical lifespan of 25+ years and are backed by an industry best 10-year warranty.

Applications include:

  • ILS Glide Path
  • ILS Localizers
  • Near Field Monitors
  • Far-Field Monitors
  • DME Antennas

Custom mounts can be fabricated in-house by Millard ensuring full system integration.

As ILS equipment is sensitive and critical for the safe operation of an airfield, Millard treats each ILS project as unique and provides custom engineering on a project-by-project basis.  Equipment deflection and specific site wind and ice loads must be considered.

Thursday, 16 March 2017 00:00

WINDSOCKS

Millard offers a complete line of frangible windsock masts that are safe, easy to use and durable.  The mast and its mechanical features offer a typical life expectancy of 20+ years.  Typical heights are 3m and 6m although other heights are available.

  • ICAO compliant as verified through 3rd party full-scale impact testing
  • Built for 170km/h wind and 12.5mm ice loading and not subject to fatigue or deformation as with pole-style masts
  • Resistant to extreme UV and saltwater exposure
  • Tilt base option allows for mast and windsock to be installed on the ground and raised into position by hand
  • Center hinge option allows the wind cone to be serviced from the ground by a single technician using a worm gear winch

Millard also offers all wind cone components in compliance with ICAO requirements:

  • Fabric windsocks
  • Basket and Swivel assemblies
  • 110V to 240V and 6.6A Circuit Series Electrical Configurations
  • Internally/Externally Lit LED Assembly
  • Solar Powered kits
  • LED Obstruction Lighting
